⚙️💪 Small Servo, Serious Upgrade for Your Traxxas
The REEFS RC 55Micro Waterproof Digital Micro Servo is designed as a direct drop-in option for Traxxas TRX-4 models with shifting servos and the TRX-4M platform. High-voltage capable with an operating range up to 8.4V, this compact servo combines all-steel gears, a CNC-machined aluminum case, and waterproof construction for reliable performance in demanding RC environments.
🏁 About the 55Micro Servo
⚡ High-Voltage Performance
The 55Micro operates from 4.8V to 8.4V, delivering up to 55 oz-in of torque and speeds as quick as 0.08 sec/60° at 8.4V.
🔧 Built for Durability
All-steel gears provide drivetrain strength, while the fully CNC-machined aluminum case adds durability and helps dissipate heat during operation.
💧 Waterproof & Programmable
Waterproof construction makes the 55Micro well suited for trail and crawling environments. The servo is also fully programmable using the optional REEFS USB Link Adapter.
✨ Features
✔ Direct drop-in fit for compatible Traxxas applications
✔ High-voltage capable
✔ 4.8V–8.4V operating range
✔ Waterproof design
✔ Durable all-steel gears
✔ Digital coreless motor
✔ CNC-machined aluminum case
✔ Fully programmable with optional REEFS USB Link Adapter
✔ 25T output spline
✔ Compact micro-servo design
📊 Specifications
-
Speed @ 6.0V: 0.11 sec/60°
-
Speed @ 7.4V: 0.09 sec/60°
-
Speed @ 8.4V: 0.08 sec/60°
-
Torque @ 6.0V: 41 oz-in (2.95 kg-cm)
-
Torque @ 7.4V: 48 oz-in (3.45 kg-cm)
-
Torque @ 8.4V: 55 oz-in (3.96 kg-cm)
-
Motor: Digital Coreless
-
Operating Voltage: 4.8–8.4V
-
Dimensions: 0.90 x 0.50 x 0.86 in (22.9 x 12.8 x 22mm)
-
Weight: 0.67 oz (19g)
-
Spline: 25T
📦 Includes
- (1) REEFS RC 55Micro Waterproof Metal Gear Digital Micro Servo
- Assorted Servo Horns
-
Mounting Hardware
🔧 Compatibility
- Traxxas TRX-4 with shifting servos
-
Traxxas TRX-4M
📝 Notes
- Recommended as an upgrade for TRX-4 and TRX-6 models with shifting servos.
- Suitable for stock/lightweight TRX-4M applications.
- Not recommended for heavily modified TRX-4M builds.
- REEFS USB Link Adapter (SEHREEFS64) required for programming and sold separately.
