Italian engineering. Smooth power. Cool performance.
The Marka Racing V2 2500KV Brushless Motor delivers high torque, precise throttle response, and exceptional durability for 1/28-scale Mini-Z racing. Developed and built in Italy, this compact motor combines premium materials with efficient cooling and a bold two-tone anodized finish that reflects Marka’s signature design style.
With improved torque output and acceleration compared to standard VE motors, the V2 series gives racers a competitive edge on both technical tracks and long straights. Its 15 mm aluminum heatsink can features multiple ventilation ports to keep temps low, while precision Japanese dual ball bearings ensure smooth, reliable operation.
⚙️ Features
-
2500KV brushless power optimized for 1/28 Mini-Z platforms
-
Aluminum heatsink can (15 mm) with front & side ventilation holes
-
Black anodized can / red anodized end-bell — Marka signature finish
-
High-quality stator windings for maximum torque and long life
-
Replaceable 6×13.5 mm rotor with 2 mm shaft (interchangeable sizes available)
-
Dual Japanese ball bearings for smooth rotation
-
Fixed timing for consistency and reliability
-
Fits Kyosho, PN Racing, GL Racing, Atomic, Xpower motor mounts
-
Compatible with MR02, MR03, AWD, F1, GLR, GLA, GLF, BZ, and more
📊 Specifications
|
Spec
|
Detail
|
|
Scale
|
1/28
|
|
Type
|
Brushless (Sensorless)
|
|
KV Rating
|
2500 KV
|
|
RPM @ 8.4 V
|
23 000 RPM
|
|
Voltage Range
|
2S LiPo / 4× NiMH (4.8 V)
|
|
No-Load Current
|
0.2 A
|
|
Timing
|
Fixed
|
|
Rotor Size
|
6.0 × 13.5 mm
|
|
Shaft Diameter
|
2 mm
|
|
Weight
|
17.3 g
|
|
Bearing Type
|
Dual Japanese Ball Bearings
|
|
Can Diameter
|
15 mm Aluminum Heatsink
|
🔧 Installation Notes
-
Use M2×4 mm countersunk screws for PN Racing motor mounts
-
Use M2×4 mm button screws for GL Racing or Atomic mounts
-
Recommended wire: Marka 22 AWG / 0.35 mm Silicone Wire (MRK-3108)
-
Screws not included
